UPVC Industrial Water Filter System 150m3h Ultra Pure Water Treatment Equipment
| Place of Origin | Shenzhen,China |
|---|---|
| Brand Name | HongJie |
| Certification | ISO 14001,ISO 9001,CE,EPA |
| Minimum Order Quantity | >=1sets |
| Price | US$300000~US$310000 |
| Packaging Details | export standard wooden case |
| Delivery Time | 1-7working days(depand on raw materials stocking) |
| Payment Terms | L/C,D/P,T/T,Western Union |
| Supply Ability | >300sets/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Main Material | UPVC | Water Quality | Resistivity ≥ 15 - 17 MΩ·cm |
|---|---|---|---|
| Flow Rate | 150T/H (Customizable) | Core Process | Double-pass Reverse Osmosis + EDI + Polishing Resin |
| Key Components | RO Membrane Modules, EDI Units | Electricity Supply | 380V/220V |
| After-Sales Service | 2-Year Warranty | Operation Mode | Fully Automatic |
| High - Temperature Resistance | ≤ 40°C (long - Term) | TOC Leaching (ppb) | 1 - 5 (initial) → 3 - 10 (long - Term) |
| Highlight | Industrial Ultra Pure Water Equipment,Customizable Ultrapure Water Systems |
||
Product Description
I.Overview
UPVC (unplasticized polyvinyl chloride, also known as rigid PVC) is mainly used in cost-sensitive scenarios and non-core processes in ultra-pure water systems. It serves as the “economical supporting role” in ultra-pure water systems, playing an irreplaceable role in pre-treatment and secondary water purification processes. Its core value lies in its cost-effectiveness and ease of installation.
II.Main process
Raw Water → Raw Water Tank → Booster Pump → Flocculant/Reducer Dosing → Activated Carbon Filter → Ultrafiltration (UF) → Scale Inhibitor Dosing → Security Filter → 1st Stage High-Pressure Pump → 1st Stage RO → pH Adjustment → Intermediate Tank → 2nd Stage High-Pressure Pump → 2nd Stage RO → Purified Water Tank → EDI Booster Pump → UV Sterilizer → Cartridge Filter → EDI System → Ultra-Pure Water Tank → Transfer Pump → TOC Removal Unit → Polishing Resin → Final Filter → Point of Use
III.Core Application Scenarios of UPVC
| Scenarios | Details |
| Pretreatment and Primary Pure Water Transportation | Raw water transportation, sand filter/carbon filter pipes, RO product water storage |
| Economical Ultra - pure Water Systems | Medical dialysis equipment, laboratory pure water systems, photovoltaic cell cleaning |
IV.Key Performance Characteristics of UPVC
| Parameter | UPVC |
| Impact on Resistivity | Water quality degrades to 15 - 17 MΩ·cm after use |
| TOC Leaching (ppb) | 1 - 5 (initial) → 3 - 10 (long - term) |
| High - temperature Resistance | ≤ 40°C (long - term) |
| Installation Cost | $10/m (cold glue bonding) |
| Service Life | 8 - 10 years |
V.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
