15M³/H Traditional Chinese Medicine (TCM) Preparation Purified Water Equipment (Customizable as Required)

  • 15M³/H Traditional Chinese Medicine (TCM) Preparation Purified Water Equipment (Customizable as Required)
  • 15M³/H Traditional Chinese Medicine (TCM) Preparation Purified Water Equipment (Customizable as Required)
Place of Origin Shenzhen,China
Brand Name HongJie
Certification ISO 14001,ISO 9001,CE,EPA
Minimum Order Quantity >=1sets
Price negotiation
Packaging Details export standard wooden case
Delivery Time 1-7working days(depand on raw materials stocking)
Payment Terms L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability >300sets/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Stable Water Quality, Low Operation Cost Capacity 15m³/h (Customizable As Required)
Water Quality Electrical Conductivity < 5μS/cm Core Technology Double-stage Reverse Osmosis (RO) + Electrodeionization (EDI)
Key Components RO Membrane Modules, EDI Modules Operation Mode Fully Automated (PLC Control)
After-sales Service 2-Year Warranty For Standard Equipment Electricity Supply 380V
Highlight

Industrial Ultra Pure Water Equipment

,

Customizable Ultrapure Water Systems
Leave a Message
Product Description
Ⅰ. Equipment Overview
With technological advancements, China's traditional Chinese medicine (TCM) sector has embraced modern reforms. TCM decoctions can now be refined into oral liquids, pills, or combined with western medicines to form tablets—offering portability and improved palatability. TCM preparation processes demand strict water quality standards: our purified water equipment meets Chinese Pharmacopoeia requirements and GMP certification, ensuring qualified water that preserves the therapeutic efficacy of TCM formulations.


II. Process Flows


Raw Water → Pressure Pump → Multi-media Filter → Activated Carbon Filter → Water Softener → Precision Filter → 1st Stage RO → Degassing Membrane → Intermediate Tank → Intermediate Pump → EDI System → Purified Water Tank → Pure Water Pump → UV Sterilizer → Micro-porous Filter → Pasteurization → Water Use Points


RO Membrane  Photo:


15M³/H Traditional Chinese Medicine (TCM) Preparation Purified Water Equipment (Customizable as Required) 0

EDI Photo:

15M³/H Traditional Chinese Medicine (TCM) Preparation Purified Water Equipment (Customizable as Required) 1


III.Parameters
Item Specification
Electricity Supply 380V
Produced Water Quality Resistivity ≥15-18.25 MΩ·cm
Core Technology Double-pass Reverse Osmosis + EDI + Polishing Resin
Key Components RO Membrane Modules, EDI Units
Operation Mode Full Automatic (PLC-controlled)
Product Features Stable Water Quality,Low Operation Cost,Reliable Performance
After-Sales Service  2-Year Warranty For Standard Equipment


IV.Design Highlights (Marketing Focus)
  1. Fully automated control (with manual override) for scheduled backwashing and regeneration.
  2. Pre-assembled unit wiring reduces on-site installation time.
  3. 1st/2nd stage RO with reflux pipes, plus chemical cleaning and disinfection devices.
  4. 304/316L stainless steel pipes in hygienic/non-hygienic designs.
  5. Options for normal temperature or hot water disinfection.
  6. Automatic stainless steel pipe welding with endoscopic inspection for leak-proof joints.
  7. Purified water tanks with breathing filters, and pipelines equipped with UV sterilizers and micro-porous filters to ensure hygiene.
  8. Integrated control and instrument systems for intuitive operation.



V. Design Standards and Basis
  1. Tailored solutions based on clients’ detailed water quality reports.
  2. Purified Water Standards in the Chinese Pharmacopoeia (current edition)
  3. JB/T 2932-1999 Technical Conditions for Water Treatment Equipment
  4. CJ/T119-2000 Standard for Reverse Osmosis Water Treatment Equipment
  5. JB/T20093-2007 Pharmaceutical Machinery Industry Standard
  6. GB/T 12771-2008 Stainless Steel Welded Tubes for Fluid Transportation


Quality Criteria:
  • Microbial count ≤10CFU/100ml
  • Endotoxin ≤0.25EU/ml
  • Electrical conductivity ≤2μS/cm (Resistivity ≥0.5MΩ·cm)


Ⅴi. Application Fields
Widely used in:


  • Pharmaceutical industry (pharmaceutical water, TCM preparation production)
  • Biotechnology sector
  • Scientific research
  • Production of patent Chinese medicines, snake-based health products, dietary supplements, etc.


VII.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
