50m3/D Seawater Desalination Unit Sea Water Filtration Plant For Offshore Drilling Platforms

  • 50m3/D Seawater Desalination Unit Sea Water Filtration Plant For Offshore Drilling Platforms
  • 50m3/D Seawater Desalination Unit Sea Water Filtration Plant For Offshore Drilling Platforms
Place of Origin Shenzhen,China
Brand Name HongJie
Model Number WY-SW-50
Minimum Order Quantity >=1sets
Price negotiation
Packaging Details export standard wooden case
Delivery Time 1-7working days(depand on raw materials stocking)
Payment Terms D/A,L/C,D/P,T/T,Western Union,MoneyGram
Supply Ability >300sets/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Water Quality TDS < 700 Mg/L Daily Output 50 Tons/day (2.08 M³/h)
Power Consumption 16.5 KW Salt Rejection Rate >98.5%
Power Supply 480V / 60Hz / Three-phase System Recovery Rate 35% (temperature & Water Quality Dependent)
Operating Pressure 3.5–5.5 MPa Dimensions 2600×1200×2035 Mm
Highlight

50m3/D Seawater Desalination Unit

,

50m3/D sea water filtration plant
Leave a Message
Product Description

I.Product Features

The seawater desalination unit is engineered with internationally advanced reverse osmosis (RO) technology and optimized system design.



  • Compact & Adaptable: Designed to meet shipyard technical specifications, including dimensional constraints and lifting lugs. Features a small footprint, easy installation, and high adaptability for marine vessels and offshore platforms.
  • User-Friendly: Simple operation and maintenance. Requires only seawater and power supply to produce water after startup.
  • High Performance: Achieves stable, reliable operation with a salt rejection rate exceeding 98.5%, effectively removing harmful components such as inorganic salts, heavy metal ions, organic matter, bacteria, and pathogens from seawater.
  • Quality Assurance: Produces water that meets China's National Drinking Water Sanitation Standard (GB5749-2006).





II.Product Specifications

Parameter Details
Model WY-SW-50
Frame Color Silver Gray (RAL 7001)
Water Quality TDS < 700 mg/L
Daily Output 50 tons/day (2.08 m³/h)
Power Consumption 16.5 kW
Salt Rejection Rate >98.5%
Power Supply 480V / 60Hz / Three-phase
System Recovery Rate 35% (temperature & water quality dependent)
Operating Pressure 3.5–5.5 MPa
Dimensions 2600×1200×2035 mm
Net Weight 710 kg
RO Membrane & Housing 3×3 elements (8040 type)
Frame Material Carbon steel with spray coating



III.System Functions

  1. Overpressure Protection: Automatically shuts down and triggers audible-visual alarms when high-pressure pump outlet pressure exceeds 6.2 MPa.
  2. Low-Pressure Protection: Activates shutdown and alarms when inlet pressure to the high-pressure pump drops below 0.05 MPa due to insufficient pretreatment water supply.
  3. Multi-Media Filter Cleaning: Equipped with manual multi-way valves for backwashing when differential pressure reaches 0.1 MPa.
  4. RO Membrane Cleaning System: Enables physical, chemical cleaning, and preservation solution injection for membrane modules.
  5. Quality Control: Automatically diverts water discharge if product water quality exceeds standards.





IV.Key Components

Component Specification
RO Membrane 8040 Series (Dow/Toray/Hydranautics)
Membrane Housing 1000 PSI, Fiberglass Reinforced Plastic (FRP)
Multi-Media Filter φ900×1650 mm, FRP
Cartridge Filter 20 m³/h, 20"×5μm×1 element, FRP
Feed Pump CNP (Southern Pump), SUS316L
High-Pressure Pump Taiwan Diamond Brand, SUS316
Electrical Components Schneider
Conductivity Meter Coreda





V.Delivery Package

  1. Water Treatment Unit
  2. Operation Manual & Video Tutorial
  3. Completion Documents:
    • Product certificate
    • Factory test report
    • Packing list
    • Equipment drawings
  4. Consumables & Spare Parts



VI.Notes

  1. Performance Conditions: Daily output is measured at 25°C inlet temperature, 35,000 mg/L salinity, and 4.5 MPa operating pressure.
  2. Customization: Available upon customer request.
