Industrial 30TPH Ultrapure Water System with Two-Pass RO and EDI for High Purity Applications

Industrial 30TPH Ultrapure Water System with Two-Pass RO and EDI for High Purity Applications

Brand Name:	Hongjie
Model Number:	HJ-UP1T
MOQ:	1set
Price:	negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	>300sets/month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

ISO 14001,ISO 9001,CE,EPA

Voltage:

380V, 220V/50HZ Etc; (Power Supply Can Be Customized)

Warranty:

1 Year

Control:

Electric Auto Control (PLC )

Desalination Rate:

≥ 99%

Material:

Stainless Steel 304/Fiberglass

Productivity:

30TPH / Custom

Product Name:

Ultrapure Water System

Filter Media:

Sand+carbon+softener+RO+EDI

Packaging Details:

export standard wooden case

Highlight:

30TPH Ultrapure Water System

Two-Pass RO UPW System

EDI Ultrapure Water Equipment

Product Description

Industrial 30TPH Ultrapure Water System with Two-Pass RO and EDI

The Industrial 30 TPH Ultrapure Water System with Two-Pass RO and EDI is engineered to deliver stable, high-purity ultrapure water for demanding industrial applications. This advanced system integrates ultrafiltration (UF), two-pass reverse osmosis (RO), EDI (electrodeionization) and polishing units to ensure consistent water quality, exceptional reliability and long-term operational efficiency.

This ultrapure water system employs a two-pass RO configuration with high-rejection membranes to effectively remove dissolved salts, organic matter and silica. The downstream EDI system further eliminates trace ions without chemical usage, enabling continuous production of ultrapure water with high resistivity and low conductivity. An optional polishing mixed bed (PMB) can be incorporated as a final treatment step to meet ultra-strict water quality requirements.

Key Features & Advantages

Ultra-High Purity Water: Two-Pass RO + EDI delivers stable ultrapure water with ultra-low conductivity
Chemical-Free Operation: EDI system eliminates acid and alkali regeneration, ensuring safer and eco-friendly operation
Industrial-Grade Reliability: Proven components and robust design for 24/7 continuous operation
High Efficiency & Water Recovery: Optimized process reduces water consumption and operating costs
Fully Automated Control: PLC + HMI for real-time monitoring and intelligent operation
Modular & Customizable Design: Skid-mounted system tailored for diverse industrial applications

Technical Specifications

Parameter	Specification
System Type	High Purity UPW System
Design Capacity	30 TPH
Operation Mode	Continuous
Recovery Rate	RO system: 70-75%
Overall Water Recovery	≥ 65%
Feed Water TDS	≤ 1,000 mg/L
Feed Water Pressure	0.2 - 0.6 MPa
Operating Pressure	0.8 - 1.6 MPa
Operating Temperature	5 - 35 °C
pH Range (Feed Water)	3 - 10
SDI (15 min)	≤ 3
Turbidity	≤ 1 NTU
Salt Rejection (RO)	≥ 99.5%
EDI Product Resistivity	≥ 18.0 MΩ*cm
Power Consumption	Customized
Control System	PLC + HMI
Automation Level	Fully Automatic
Installation Type	Skid-mounted / Containerized (optional)
Design Standard	Customized / International Standards
Service Life	≥ 15 years (key equipment)

System Selection Guidance

Identify Your Water Treatment Requirements

Clarify the following aspects to determine the optimal equipment configuration for your specific needs:

Water Quality Analysis

Identify specific water quality challenges such as:

Sediment exceeding standards
Scale formation issues
Turbid water conditions
Microbial contamination
Heavy metal exceedances
Other specific contaminants

Required Water Standards

Define your target water quality specifications:

Softened water
Pure water
Ultra-pure water
Iron and manganese removal
Sediment removal
Sterilization requirements

Water Consumption Profile

Assess your operational water usage patterns:

Peak consumption periods
Daily operational hours
Maximum hourly water consumption
Average hourly water consumption

System Recommendation Examples

5 tonnes per hour water softening equipment
3 tonnes per hour reverse osmosis water purification equipment

Need Assistance Determining Your Requirements?

Water Quality Analysis: Submit a water sample for comprehensive testing
Water Standards: Specify your industry application for appropriate recommendations
Water Consumption: Our engineering team can calculate optimal system sizing based on your operational needs
