Safe Reliable 95m3/H Ultra Pure Water Equipment For Nuclear Power Plant Boiler Feed Water
| Place of Origin | Shenzhen,China |
|---|---|
| Brand Name | HongJie |
| Certification | ISO 14001,ISO 9001,CE,EPA |
| Minimum Order Quantity | >1set |
| Price | US$220100~US$226000 |
| Packaging Details | export standard wooden case |
| Delivery Time | 1-7working days(depand on raw materials stocking) |
| Payment Terms | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability | >300sets/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Flow Rate | 95m³/H (Customizable) | Electrical Conductivity | ≤0.1 μS/cm(25°C) |
|---|---|---|---|
| Core Process | Double-pass Reverse Osmosis + EDI + Polishing Resin | Key Components | RO Membrane Modules, EDI Units |
| Electricity Supply | 380V/220V | After-Sales Service | 2-Year Warranty |
| Operation Mode | Fully Automatic | Product Features | Stable Water Quality,Low Operation Cost,Reliable Performance |
| Dissolved Hydrogen (H₂) | 0.3 - 1.5 Ppm | Boric Acid (H₃BO₃) | 0 - 2300 Ppm (Regulated Concentration) |
| Highlight | 95m3/H Ultra Pure Water Equipment,Reliable Ultra Pure Water Equipment,95m3/H ultra pure water machine |
||
Product Description
Safe and Reliable 95 cubic per hour ultra pure water system for nuclear power plant boiler feed water
I. Overview
The application of ultra-pure water in nuclear power plant boiler feedwater (reactor coolant) is a core safeguard for nuclear safety. In current water-cooled reactor technology, ultra-pure water remains an indispensable cornerstone of nuclear safety, with its purity directly impacting reactor control efficiency, equipment lifespan, and radiation protection safety.
Ultra-pure water in nuclear power plants is not only boiler feedwater but also the lifeblood of reactor control and radiation protection. The ultra-pure water produced by Hongjie's ultra-pure water equipment can provide you with extreme purity, multiple barriers, and ensure safety above all else.
II. Process
Raw Water→ Pretreatment(Multi-media Filtration + Softening)→ Double-stage RO→ Membrane Degassing→ Mixed Bed Polishing(Nuclear-grade Resin)→ High-temperature Refinement(200°C +)→ Boron Adsorption Column(Specific Resin)→ Terminal Ultrafiltration
III. Parameters
| Parameter | Pressurized Water Reactor (PWR) Standard | ||||
| Electrical Conductivity (25°C) | ≤0.1 μS/cm | ||||
| Dissolved Hydrogen (H₂) | 0.3 - 1.5 ppm | ||||
| Boric Acid (H₃BO₃) | 0 - 2300 ppm (Regulated Concentration) | ||||
| Chloride Ion (Cl⁻) | ≤5 ppt | ||||
| Lithium Ion (Li⁺) | 0.2 - 2.2 ppm | ||||
| Desalination Rate | > 99.7% | ||||
| DO | < 5 ppb |
IV. Cutting-edge technology trends
Online boron monitoring
Radiation-resistant materials
Intelligent control
V. Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
