Stainless Steel 304 High-Pressure Resistant Cartridge Water Filter With Advanced Corrosion Resistance

304 Stainless Steel Cartridge Water Filter with High Accuracy and Corrosion & Pressure Resistance

I.Description

The 304 Stainless Steel Cartridge Water Filter is a high-precision filtration system used in water treatment applications. Its primary purpose is to remove fine particles, suspended solids, and contaminants from water, protecting downstream equipment like reverse osmosis membranes, ultrafiltration membranes, and softeners, thereby extending the lifespan of the entire system.

II.Components

• Housing: Constructed from durable 304 stainless steel, it offers exceptional corrosion resistance, high-pressure endurance, and a long operational lifespan.

• Filter Element: Common materials include meltblown, pleated, wirewound, and activated carbon filters, designed to efficiently capture impurities.

• End Cap/Clamp: Ensures proper sealing and secure attachment, allowing for easy replacement of the filter element.

III.Key Features

• High Precision Filtration: Typically ranges from 0.1 to 50 microns, with 1 µm, 5 µm, and 10 µm filters being most common for precise water treatment.

• High Pressure Resistance: Built with 304 stainless steel, capable of withstanding water pressures up to 6-10 bar (or higher).

• Corrosion Resistance: Ideal for use in drinking water, ultrapure water, industrial cooling systems, and other applications that require resistance to corrosive conditions.

• Easy Maintenance: Filter elements are easy to replace, leading to reduced maintenance time and low operational costs.

IV.Applications

• Pre-filtration for Reverse Osmosis (RO) and Ultrafiltration (UF) systems

• Drinking water purification for residential and industrial use

• Food and beverage production filtration

• Water treatment in the pharmaceutical, electronics, and chemical industries

• Boiler feed water and circulating cooling water filtration

Identify needs

Clarify the following issues, and you can determine the right equipment for you.

Water quality problems

Example 1: sediment exceeds the standard/scale / turbid water / microbial exceeds the standard/ heavy metal exceeds the standard/money Yu exceeds the standard, etc.

Water standard

Example 1:Softened water/pure water/ultra-pure water/iron and manganese removal/sediment removal/sterilisation, etc.

Daily Water Consumption

Example 1:Whether there is a concentrated water consumption period/water consumption time/peak maximum water consumption/hourly average water consumption

Conclusion Example

5 tonnes per hour water softening equipment.

3 tonnes per hour reverse osmosis water purification equipment

If you can't answer the above questions clearly?

1. Daily Water Consumption: Just mail a bottle of water sample

2. Water Standard: Just tell me your industry.
