5 TPH Bipolar EDI Ultrapure Water System for Industrial High-Purity Applications

I.Conception

The 5 TPH Bipolar EDI Ultrapure Water System produces consistently high-quality ultrapure water by integrating advanced bipolar electrodeionization technology with reliable upstream reverse osmosis treatment. This ensures low conductivity, stable performance, and minimal chemical consumption.

II.Key Features & Advantages

Advanced Bipolar EDI Technology
Ensures stable, continuous production of ultrapure water without chemical regeneration.

High Purity & Consistent Quality
Delivers resistivity up to 18 MΩ·cm, meeting the requirements of high-end industrial applications.

Low Operating Cost
Eliminates the need for acid and caustic chemicals, reducing operating and maintenance expenses.

Compact & Modular Design
Space-saving structure, easy integration with existing RO systems.

Environmentally Friendly
Zero chemical discharge and minimal wastewater generation.

Fully Automated Operation
PLC-controlled system with real-time monitoring and alarms.

Long Service Life
High-quality EDI modules and components ensure reliable long-term performance.

III.Product Water Quality (EDI Outlet)

• Flow Rate: 5 m³/h (5 TPH)
• Resistivity: ≥ 15–18 MΩ·cm (25 °C)
• Conductivity: ≤ 0.056 μS/cm
• Silica: ≤ 0.02 ppm
• TOC: ≤ 20 ppb
• Recovery Rate: ≥ 90%
• Continuous Operation: 24/7

Identify needs

Clarify the following issues, and you can determine the right equipment for you.

Water quality problems

Example 1: sediment exceeds the standard/scale / turbid water / microbial exceeds the standard/ heavy metal exceeds the standard/money Yu exceeds the standard, etc.

Water standard

Example 1:Softened water/pure water/ultra-pure water/iron and manganese removal/sediment removal/sterilisation, etc.

Daily Water Consumption

Example 1:Whether there is a concentrated water consumption period/water consumption time/peak maximum water consumption/hourly average water consumption

Conclusion Example

5 tonnes per hour water softening equipment.

3 tonnes per hour reverse osmosis water purification equipment

If you can't answer the above questions clearly?

1. Daily Water Consumption: Mail a bottle of water sample

2. Water Standard: Just tell me your industry.

3. Water Consumption: We can help you calculate the water consumption.
