| Brand Name: | Hongjie |
| Model Number: | HJ - PWMi10T |
| MOQ: | 1set |
| Price: | US$29200~US$29500 |
| Payment Terms: | T/T |
| Supply Ability: | >300sets/month |
I.One-stage RO process:
Raw Water → Pressurized Pump → Multimedia Filter → Activated Carbon Filter → Water Softener → Precision Filter → Primary RO → Pure Water Tank → UV Sterilizer → Water Point
II.Parameters
| Item | Specification | ||||||
| Production capacity | HJ-PWMi10T | ||||||
| Flow rate | 10m³/h | ||||||
| Electricity Supply | 380V | ||||||
| Produced Water Quality | Conductivity < 10μs/cm | ||||||
| Core Technology | one-stage Reverse Osmosis (RO) | ||||||
| Key Components | RO Membrane Modules | ||||||
| Operation Mode | Full Automatic (PLC-controlled) | ||||||
| Warranty period | 2-Year | ||||||
III.Deatails of process equipment
| Name | Container | Brand | Usage | ||||
| Pressurized Pump | SUS-304 | CNP | Provide initial water source power | ||||
| Multimedia Filter | Stainless steel, carbon steel,or FRP | China | Provide pre-treated and purified water source | ||||
| Activated Carbon Filter | Stainless steel, carbon steel, or FRP | China | Remove sediments, manganese, rust, colloidal substances, and other particles larger than 20 μm | ||||
| Water Softener | SUS-304 | China | Eliminates calcium ions (Ca²⁺) and magnesium ions (Mg²⁺) | ||||
| Precision Filter | SUS-304 | China | Remove fine particles and tiny colloidal particles from water, reducing its turbidity to 1 degree | ||||
| Intermediate Tank | SUS-304 | China | Temporarily stores the effluent from the previous treatment process | ||||
| Purified Water Tank | SUS-304 | China | Store the purified water after treatment | ||||
| Pure Water Pump | SUS-304 | CNP | Pressurizes and delivers the treated purified water to each water-using point | ||||
| RO Membrane | BW30PRO-365 | USA,Dupont | Removes dissolved salts, organic matters, bacteria, viruses and other impurities from water to produce high-purity purified water. | ||||
| UV Sterilizer | 100w*2 | China | Kill bacterial in water. UV for direct drinking water. Ozone generator for bottle water | ||||
| Microporous Filter | SUS-304 | China | Intercepts impurities such as particles, colloids, bacteria, and organic matters in water with a particle size larger than 0.1-10μm | ||||
IV.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
